Yamaha xmv4140 Amps Specifications

Input Sensitivity

+4dBu

S/N Ratio

> 100dB

Power Consumption

150W

THD+N

< 0.2%

Frequency Response

0dB, ±1.0dB

Crosstalk

< -60dB

Maximum Input Level

+24dBu

Input Impedance

20kΩ (balanced), 10kΩ (unbalanced)

Analog Input

Euroblock x 2 (6P, balanced)

Digital Input / Output

RJ45 x 2 (YDIF IN / OUT)

Speaker Output

Barrier Strip x 4 pairs

Network

RJ45 x 1

Remote, Fault Output

Euroblock (3P) x 1

AC IN

AC Inlet x 1

Cooling Fan

3-Speed fan x 2, front-to-back airflow

Power Requirements

100V, 120V, 230V-240V; 50Hz/60Hz

Dimensions (WxHxD)

480mm x 88mm x 422mm

Weight
