Digital Performance
A-D Dynamic Range | 109 dB A-weighted (all inputs) |
D-A Dynamic Range | 106 dB A-weighted (line outputs 1-2) 108 dB A-weighted (line outputs 3-4) |
Supported sample rates | 44.1 kHz, 48 kHz, 88.2 kHz A 96 kHz |
Clock jitter | <250 ps |
Microphone Inputs
Frequency Response | 20 Hz ± 0.5 dB, 20 kHz ± 0.1 dB (min. gain) |
THD+N | -96 dB (1 kHz, –1dBFS, 20 kHz BW) |
Noise EIN | –122 dBu CCIR-RMS (measured at 60 dB of gain with 150 ohm termination) |
Maximum input level | +9 dBu (without pad) |
Line Inputs (Front Panel)
Frequency Response | 20 Hz ± 0.5 dB, 20 kHz ± 0.1 dB (min. gain) |
THD+N | -80 dB (1 kHz, –1dBFS, 20 kHz BW) |
Noise (NiPoS) | –105 dBFS CCIR-RMS (measured at min. gain with 50 ohm termination) |
Maximum input level | > +28 dBu |
Line Inputs (Rear Panel)
Frequency Response | 20 Hz ± 0.5 dB, 20 kHz ± 0.1 dB (min. gain) |
THD+N | –82dB (1 kHz, –1dBFS, 20 kHz BW) |
Noise (NiPoS) | 107dBFS CCIR-RMS (measured at min. gain with 50 ohm termination) |
Maximum input level | +16dBu |
Instrument Inputs
Frequency Response | 20 Hz ± 0.3 dB, 20 kHz ± 0.1 dB (min. gain) |
Noise EIN | –103 dBFS CCIR-RMS (measured at min. gain) |
Maximum input level | +8 dBu (without pad) |
Line Outputs 1 & 2
Maximum Output Level (0 dBFS) | +11 dBu, balanced |
THD+N | -100 dB (1 kHz, –1dBFS, 20 kHz BW) |
Weight and Dimensions
Weight:1.18Kg
Height:50mm
Width:210mm
Depth:180mm
